BLDC Ceiling Fan 230V

BLDC 230V Ceiling Fan is made to the highest quality giving the customer years of trouble free use.

Because of the motor design, the fan is operated by a wall switch. The Vari-Fan does not come with a switch, but one can be purchased from us

Energy-saving, Environmental Protection,New Popular Style, Long Using Life,Low Noise,convenient To Use, Wind strong, Shell Firmly.

Description

Sr. No.	Discerption	Parameter	Test Report	Remark
1	Type of Motor	BLDC Motor	BLDC Motor	Yes
2	Rated voltage	230 V	230 V	Yes
3	Operating Voltage Range	100 Volt to 270 Volt	90 Volt to 300 Volt	Yes
4	Blade Diameter (Sweep 48”/1200mm)	1200 mm	1200 mm	Yes
5	Body & Blade: Body Aluminum & Blade Three Leaves Aluminum	Powder Coated	Powder Coated	Yes
6	Power Consumption: (+-10%)	<30 Watt	30 Watt	Yes
7	Air delivery: > 150 CMM (cubic meter per minute)	>210 CMM	>215 CMM	Yes
8	RPM	340	352	Yes
9	Bearings: Two nos. ball bearings	2 ZZ	2 ZZ	Yes
10	Reverse polarity protection: Fan should not work with Reverse Polarity.	Complied	Complied	Yes
11	Temperature Test (<5 Degree)	Complied	Complied	Yes
12	Insulation Test	Complied	Complied	Yes
13	Reliability Test	Complied	Complied	Yes
14	Noise Test	<30 Db	<27 Db	Yes
15	Operating Temperature Range	0-65 Degree	0-65 Degree	Yes
11	Speed Electronically Control	5 Speed	5/4 Speed	Yes
